Description
Performance
- Maximum engine power at 2,250 rpm: 85 hp*
- Maximum torque at 1,400 rpm: 291 Nm
- Maximum PTO power at rated engine speed: 70 hp**
- *Certified to BU AU 141a: (1971)
- ** Manufacturer’s estimate
Engine
- Type: Perkins / 4.41
- No. of Cylinders: 4
- Injection: Direct
- Bore: 101 mm
- Stroke: 127 mm
- Capacity: 4.41 L
- Compression Ratio: 15.3 : 1
- Aspiration: Natural
- Starting Aid: Thermostart
- Throttle Control: Hand and foot
- Cooling: Water
- Air Cleaner Type: Oil bath
- Air Pre-Cleaner: Over Bonnet, air swirl
- Fuel Filter: Dual, high capacity
- Exhaust: Vertical muffler
- Oil Cooler: Water cooled
Electrics
- Voltage: 12 V, Negative Earth
- Battery: 110 Ah
- Starter: 2.8 kW
- Alternator: 45 Amp
Clutch
- Type: Dual clutch
- Diameter: 305 x 254 mm
- Lining Material: Cerametallic
Transmission
- Type: Sliding Spur
- Number of Gears: 8 forward, 2 reverse
- Road speed at 2,200 engine rpm with 18.4 / 15 – 30 rear tyres:
- Forward 1: 2.7 kph
- Forward 2: 3.7 kph
- Forward 3: 5.4 kph
- Forward 4: 6.8 kph
- Forward 5: 10.4 kph
- Forward 6: 15.2 kph
- Forward 7: 20.8 kph
- Forward 8: 27.9 kph
- Reverse 1: 3.5 kph
- Reverse 2: 14.1 kph
Power Take Off
- Type: Live
- Engine speed at 540 PTO rpm: 1,789 rpm
- Shaft Diameter: 35 mm
- No. of Splines: 6
Hydraulics
- Functions: Draft control, Position control, Response control, Constant pumping
- Pump Type: 4-Piston Ferguson Pump
- Maximum Oil Flow: 16.7 L/min
- Maximum Pressure: 21.2 MPa (normal operating temp)
- Max. Lift Capacity: 2,145 kg
- Lower Links: With cat. I & II interchangeable balls
Front Axle & Steering
- Front Axle: Box Section, Adjustable
- Steering: Hydrostatic
Rear Axle and Brakes
- Rear Axle: Straddle with epicyclic reduction
- Brake Type: Oil immersed, multi-disc
- Braking Area: 1,774 sq. cm
- Brakes Actuation: Hydraulic
- Parking Brake: Hand Lever operated
Instrumentation
- Gauges: Tachometer, Hourmeter, Fuel level, Battery condition, Water temperature
- Warning Lights: Direction indicators, Battery charge, Headlight main beam, Low engine oil pressure, Brake lights
Tyres
- Front: 7.50 – 16 (6PR)
- Rear: 18.4 / 15 – 30 (6PR)
Track Adjustment
- Front: 1,271 – 1,881 mm
- Rear: 1,432 – 2,134 mm
Weights and Dimensions
- Gross Weight: 2,440 kg
- Wheelbase: 2,286 mm
- Overall Length: 3,760 mm
- Overall Width (min): 1,871 mm
- Height over Exhaust: 2,485 mm
- Height over Steering Wheel: 1,781 mm
- Turning Circle (without brakes): 7,502 mm
- Ground Clearance (under gear box): 501 mm
Capacities
- Fuel Tank: 108.0 L
- Engine Oil Pump: 7.5 L
- Cooling System: 15.2 L
- Hydraulic System: 36.0 L
- Hydrostatic Steering Reservoir: 2.0 L
- Oil Bath Air-Cleaner: 0.71 L
- Brake Oil: 0.25 L
Standard Equipment
Weight frame without weights, standard toolbox with tools, Top link, Top link ends (Cat-I & II), Check chains, Spring operator’s manual.
Optional Equipment
Front end weights, swinging drawbar, sun canopy.
