Description
Performance
- Maximum engine power at 2,200 rpm: 75 (B.S) hp
- Maximum torque at 1,400 rpm: 290 Nm
- Maximum PTO power at rated speed: 69.5 hp**
- PTO power at 540 rpm: 63.0 hp
- *Certified to BU AU 141a: (1971)
- ** Manufacturer’s estimate
Engine
- Type: Diesel / 4.248
- No. of Cylinders: 4
- Injection: Direct
- Bore: 101 mm
- Stroke: 127 mm
- Capacity: 4.071 L
- Compression Ratio: 16:1
- Aspiration: Natural
- Starting Aid: Thermostat
- Throttle Control: Hand and foot
- Cooling: Water
- Air Cleaner Type: Oil bath
- Air Pre-Cleaner: Over Bonnet
- Fuel Filter: Dual, high capacity with sedimentor
- Exhaust: Vertical muffler under bonnet
Electrics
- Voltage: 12 V, Negative Earth
- Battery: 110 Ah
- Starter: 2.8 kW
- Alternator: 45 Amp
Clutch
- Type: Dual clutch
- Diameter: 305 x 254 mm
- Lining Material: Cerametallic
Transmission
- Type: Sliding Spur
- Number of Gears: 8 forward, 2 reverse
- Road speed at 2,200 rpm with 16.9 / 14 – 30 rear tyres:
- Forward 1: 2.3 kph
- Forward 2: 3.4 kph
- Forward 3: 4.7 kph
- Forward 4: 6.3 kph
- Forward 5: 9.3 kph
- Forward 6: 13.6 kph
- Forward 7: 18.6 kph
- Forward 8: 25.0 kph
- Reverse 1: 3.2 kph
- Reverse 2: 12.7 kph
Power Take Off
- Type: Live
- Engine speed at 540 PTO rpm: 1,789 rpm
- Shaft Diameter: 35 mm
- No. of Splines: 6
Hydraulics
- Functions: Draft control, Position control, Response control, Constant pumping
- Pump Type: Reciprocating Ferguson Pump
- Maximum Oil Flow: 16.7 L/min
- Maximum Pressure: 21.2 MPa (at normal temp)
- Max. Lift Capacity: 2,145 kg
- Lower Links: With Cat. I & II interchangeable balls
Front Axle & Steering
- Front Axle Type: Heavy Duty Box Section, Adjustable
- Steering Type: Hydrostatic
Rear Axle and Brakes
- Rear Axle: Straddle with epicyclic reduction unit
- Brake Type: Oil immersed, multi-disc
- Brake Pedal: Pendant
- Braking Area: 1,774 sq. cm
- Brakes Actuation: Hydraulic
- Parking Brake: Hand lever operated
Instrumentation
- Gauges: Technometer, Hourmeter, Fuel level, Battery condition, Water temperature
- Warning Lights: Direction indicators, Battery charge, Headlight main beam, Low engine oil pressure, Brake lights
- Auxiliary Socket: Yes
Tyres
- Front: 7.50 – 16 (6PR)
- Rear: 16.9 / 14 – 30 (6PR)
Track Adjustment
- Front: 1,271 – 1,881 mm
- Rear: 1,423 – 2,134 mm
Weights and Dimensions
- Gross Weight: 2,355 kg
- Wheelbase: 2,170 mm
- Overall Length: 3,760 mm
- Overall Width (min): 1,970 mm
- Height over Exhaust: 2,485 mm
- Height over Steering Wheel: 1,730 mm
- Turning Circle with Brakes: 7,260 mm
- Turning Circle without Brakes: 8,095 mm
- Ground Clearance under Gearbox: 465 mm
Capacities
- Fuel Tank: 108.0 L
- Engine Pump: 7.5 L
- Cooling System: 15.2 L
- Hydraulic System: 36.0 L
- Hydrostatic Steering Reservoir: 2.0 L
- Oil Bath Air-Cleaner: 0.71 L
- Brake Oil: 0.25 L
Standard Equipment
Weight frame without weights, standard toolbox with tools, Top link, Top link end, Cat-I & II balls, Check chains, Stabiliser chains, Spring suspension seat, Flat top fenders, Operator’s manual.
Optional Equipment
Front end weights, swinging drawbar, sun canopy, pintle hook, 9-hole drawbar.
